5600 Mechanical Control Valve

5600 Mechanical Control Valve

• Simple mechanical design is easy to use;

• Two valve body designs: one for downflow regeneration and one for upflow (covers every valve in the 5600 family - quick access to all internal components);

• Injector/drain modules containing the brine valve, flow controls, and injector are removable from the valve's exterior;

• Ruggedly-built timer is designed with heavy-duty 3/8" wide plastic gears;

• 5600 controls are user-friendly;

• Non-corrosive, UV-resistant, fiber-reinforced polymer valve body;

• Economical - small annual power consumption; keeps the time and activates the piston/valve mechanics with a single motor;

• Designed with double backwash.

Specifications

Valve Material: Fiber-reinforced polymer;

Inlet/Outlet: 3/4", 1", 1-1/4";

Cycles: 7;

Continuous Flow Rate(15 psi drop): 20 GPM;

Peak Flow Rate(25 psi drop): 26 GPM;

Cv (flow at 1 psi drop): 5;

Max. Backwash (25 psi drop): 7 GPM;

Downflow/Upflow: Both;

Adjustable Cycles: Brine fill only;

Time Available: 180 minutes per cycle;

Distributor Pilot: 13/16" or 1.05" O.D.;

Drain Line: 1/2" NPTF;

Injector brine system: 1600;

Brine Line: 3/8";

Mounting base: 2-1/2"-8 NPSM;

Height from top of tank: 7".
